Temperature Transmitter TT61

Temperature Transmitter TT61

· Multiple signal output types, suitable for various processing equipment
· Five installation structures, suitable for various installation environments
· The protection level is IP65

Share This Items :

Description

The TT61 series temperature transmitter is a sensor specially designed for industrial applications .
It is specially designed for lightning surge , electrostatic discharge , group pulse , pressure
resistance, etc., and has strong anti-interference ability . There are five installation methods :wall
mounted, air pipe/water pipe, split , and clamp . Three output modes of current , voltage, and
thermal resistance are optional. Strong onsite trial installation capability . Spring screws and
terminal posts are designed for quick installation. It can be widely used in computer rooms ,
HVAC, buildings , storage and other places where temperature measurement and control are
required.and control are required.

Additional information

Sensor

High-precision thermal resistance, see selection table
(resistance output type)/PT1000, Class A (analog output type)

Accuracy

Typical 0.2…0.5℃@0/25℃, see order reference
No.±0.3℃@25℃, see temperature accuracy curve for details

Housing material

PC housing, stainless steel
probe (6mm) and casing

Temperature

-40…70℃, 0…95%RH(Non-condensing)

IP grade

IP65

Output

4…20 mA or 0…10 VDC, 0…5 VDC

Power supply

Voltage type 15…35 VDC/24 VAC±20%
Current type 18.5…35 VDC (RL=500Ω) 8.5…35 VDC(RL=0Ω)

Output load

(Analog output type)≤500 Ω (Current type),
≥2 KΩ(0…5V), ≥3 KΩ(0…10V)
